| Specifications | Part Number |
|---|---|
| 2 x AN-6 Inlets and AN-6 Return. 1/8″ NPT Gauge Port. Base Pressure Range of 40-75PSI (2.75-5.2Bar). Boost Referenced (1:1 Ratio). Boost Reference Port is 1/16″ NPT. Dimensions are 94mm high, 62mm wide and 60mm deep with no fittings. E85 and PUMP Fuel Safe. Bypass Rate of 550LPH. | FPR-501BK |
AN Male Flare Straight
| AN-4 | RWF-920-04-06BK |
| AN-6 | RWF-920-06BK |
| AN-8 | RWF-920-08-06BK |
| AN-10 | RWF-920-10-06BK |
Barb Straight
| 5/16″ | RWF-414-06-05BK |
| 3/8″ | RWF-414-06-06BK |
Barb 90deg
| 5/16″ | RWF-415-06-05BK |
| 3/8″ | RWF-415-06-06BK |
AN Male Flare Straight Long
| AN-6 | RWF-920-06LBK |
AN Male Flare 45deg
| AN-6 | RWF-923-06BK |
AN Male Flare 90deg
| AN-6 | RWF-922-06BK |
| AN-8 | RWF-922-08-06BK |
Banjo Kit
| AN-6 | RWF-909-06BK |
AN Female Swivel
| AN-6 | RWF-907-06BK |
AN ORB Male
| AN-6 | RWF-921-06-06BK |
| AN-8 | RWF-921-06-08BK |
1/8″ NPT Port
| RWF-813-06-02BK |
M10x1.0 port
| RWF-813-06-M10BK |
Blanking Plugs
| Int Hex Plug | RWF-814-06BK |
| Ext Hex Plug | RWF-813-06BK |
