| Specifications | Part Number |
|---|---|
| AN-10 ORB Feed (new vortex design to promote flow) AN-8 ORB Supply/Return/Overflow Triple set of Stainless Steel Electrical Terminals (allowing fuel pumps to be staged) Can be configured with single, twin or triple fuel pumps Includes 10mm barb inlet fittings, PTFE hose and 3 fuel pump strainers Features Viton O-rings and Teflon in-tank hose suitable for E85 Comes with 2 sets of O-rings to allow for 38mm & 39-40mm fuel pumps (pre-fitted to suit 39-40mm) 2.8L Capacity When Used with a Single Pump 2.6L Capacity When Used with a Twin Pump 2.4L Capacity When Used with a Triple Pump Height – 215mm Diameter – 140mm Depth – 195mm |
ALY-059BK |
Compatibility List
| Raceworks | Ti Automotive (Walbro) |
|---|---|
| EFP-500 EFP-501 EFP-800 |
F90000262* F90000267* F90000274* F90000285* F90000295* GSS340 GSS341 GSS342 GSS350 GSS351 GSS352 |
